ICR18650 22.2V2600mAh lithium ion battery pack
CE approved 3.7V2200mAh Li-ion 18650 battery made in China
| Battery Type | Cylindrical lithium-ion battery cell |
| Battery Model | ICR18650 3.7V2200mah |
| FOB(shenzhen) | USD0.72-0.78/pc Get Latest Price |
| MOQ | 1000pcs |
| Supply Ability | 5000000pcs per month |
| Certification | CE, ROHS, UL, IEC, MSDS, UN38.3 |
| Payment Terms | TT,L/C,Western Union, Paypal |
| Lead time | 15-20days(5-7 days for samples) |
Specification
1. Type: Rechargeable lithium-ion cylindrical cell
2. Model: ICR18650
3. Dimension:Φ=18.0±0.2mm H=65.0±0.5mm
4. Nominal voltage: 3.7v
5. Nominal capacity: 2200mAh (Discharge 0.2C, 0.5C, 1C to 2.75v)
6. Minimum Capacity : 2150mAh (Discharge 0.2C, 0.5C, 1C to 2.75V)
7. Recommended charging conditions:440~1100mA to 4.2V, end current less than 44mA
8. Max. Continuous discharge current: 4400mA
9. Continuous discharge current:1C
10. Burst discharge current: 3C
11. Cycle life: 500cycles
12. Weight: Approximately 42g
13. Internal resistance: <80mΩ
14. Charging voltage: 4.200±0.05V
15. Self-discharge rate: less than 1% per year
16. Certificates: CE, RoHS, MSDS, UN38.3
17. Temperature:Charge 0~+45°C, Discharge: -20~+60°C, Storage: -5~+35°C
Advantages
1. Long working life
2. Low self-discharge rate
3. Wide working temperature range
4. Environmental-friendly
5. Application in many industrial purpose
Application
The batteries are widely used in miner lights, LED light, emergency lights, flashlights, laptop, portable DVD, wireless communication product, power tools and etc.
Lithium-ion Battery Other sizes
| LI-ION BATTERY | |||||
| Model | Nominal Voltage (V) | Nominal Capacity (mAh) | Dimension (mm) | Weight (gram) | |
| Diameter | Height | ||||
| ICR10250 | 3.7V | 150 | 10.2 | 25 | 6 |
| ICR10430 | 3.7V | 320 | 10.2 | 43 | 9 |
| ICR10440 | 3.7V | 360 | 10.2 | 44 | 10 |
| ICR14250 | 3.7V | 280 | 14.1 | 24.7 | 8 |
| ICR14430 | 3.7V | 650 | 14.1 | 42.7 | 18 |
| ICR14500 | 3.7V | 700 | 14.1 | 49.7 | 19 |
| ICR17335 | 3.7V | 650 | 16.8 | 33 | 18 |
| ICR17500 | 3.7V | 110 | 16.8 | 49.5 | 4 |
| ICR17650 | 3.7V | 1550 | 16.8 | 64.5 | 45 |
| ICR18490 | 3.7V | 1400 | 18.2 | 48.5 | 33 |
| ICR18650 | 3.7V | 2200 | 18.2 | 64.7 | 47 |
| ICR26650 | 3.7V | 3300 | 26 | 64.7 | 90 |
Services
– OEM & ODM Service Acceptable
-Trade terms: EXW, FOB, CIF,DDU
– Package: white box + export carton or Customization
– Delivery method: By sea or By air or By courier
– Warranty time: 12 months
